Next 70 – 4500 rpm

Automatic Cutter
Project Description
  • SAVE FABRIC WITH ZERO BUFFER
  • SAVE ON RUNNING AND MAINTENANCE COSTS
  • MAXIMUM PRODUCTIVITY AND FLEXIBILITY
  • LOW POWER CONSUMPTION

It is the most productive and versatile of the entire range of cutters, with the possibility to cut non-stop lays of any material, up to 7 cm compressed. The control of all functions by latest generation digital technology allows top speed, precision and reliability, together with low power consumption. An automatic system to digitally control in real time the knife bending guarantees the maximum cutting precision. Possibility to set different profiles allow to cut from single ply up to highest ply lays, by keeping same level of performances.

TECHNICAL SPECIFICATIONS: • Max cutting thickness 7cm compressed • Power plants 9 kWĀ  + 18 kW (single pump) • Average power consumption approx. 12 kWĀ  (single pump) • Standard cutting window 180 cm. • Available width 180 – 220 cm • Standard 4500 rpm – HM 6000 rpm • Environment temperature from 10° to 40° C • Humidity from 30% to 80% without condensation • Voltage 400 V 3Ph 50/60 Hz.

Project Details
Power Plants

9 kW + 18 kW (single pump)

Power Consumption

approx. 12 kW (single pump)

Standard Cutting Window

180 cm.
